Rod with locking slider, Polyamide GF black; 1121-115
with 3 locking points
100% original guarantee
Return within 30days
Free delivery on all orders
Assembly instruction:
Rod has to be shortened for door height 800-1300 mm.
Akeneo Note:
For door height 800 - 1300 with 2 to 3 locking points.
For door height 1300 - 1600 with 3 locking points.
Internal Reference:
1121-115
Barcode:
1121-000115-0000000
Product Type:
Rod
Material:
Polyamide GF
Program:
1121
Surface:
black
Catalog sheet:
3ZA-340
Connecting rod position:
Outside the sealing, top or bottom
Number of Possible Locking Points:
2 points, 3 point
Flat Bar Outside:
Flat rod with locking slider
For Door Height:
800-1600
Dimension L:
475 mm
No Specifications
View All Products
Here you can find the product data sheets and CAD files of this product
